# The Basics of VHF and UHF Signal Propagation

The Electromagnetic Spectrum – The electromagnetic spectrum
is a continuum of all electromagnetic waves arranged according to frequency
and wavelength. Electromagnetic radiation is classified into types according
to the frequency and length of the wave.  Visible light that comes from
two of the many types of electromagnetic radiation. In order of increasing
frequency the electromagnetic spectrum consists of radio waves, microwaves,
rays.

An electromagnetic wave consists of the electric and magnetic components.
These components repeat or oscillate at right angles to each other and to
the direction of propagation, and are in phase with each other.

All electromagnetic energy, regardless of frequency or wavelength, passes
through a perfect vacuum at the speed of light (300 million meters per
second) in the form of sinusoidal waves.

The Radio Spectrum – As radio and TV DXers, we are of
course most interested in the “radio” portion of the electromagnetic
spectrum, which exists between the frequencies of 10 Kilohertz and 300
Gigahertz, with wavelengths from 30,000 kilometers to 1 millimeter.  As
the frequency of a signal is increased, its wavelength becomes shorter.
For example, an electromagnetic wave at 750 KHz in the middle of the AM
broadcast band has a wavelength of approximately 400 meters.  As we
increase the frequency to 100 MHz in the middle of the FM band, the
wavelength decreases to about 3 meters.

The frequencies of interest to the FM and TV DXer are situated within
the
Very High Frequency (VHF) and Ultra High Frequency (UHF) regions of the
30 and 300 Megahertz, while UHF is situated between 300 and 3,000
Megahertz. The frequencies used for the FM band and television channels 2 through 13
lie within the VHF portion of the electromagnetic spectrum, while television
channels 14 through 83 are within the UHF portion of the spectrum.

Signal Propagation – When we refer to signal propagation, we are talking about
the radio signal getting from one place to another, presumably from the
station’s transmitting antenna to the receiver’s antenna.  Signals at VHF
and UHF frequencies can be propagated by a variety of means or “modes”.
Depending on the particular mode that is dominate at the time of reception,
the distances covered by VHF and UHF signals can extend hundreds or even
thousands of miles.  Here are some of the more common modes for VHF and
UHF propagation:

Ground Wave – Ground
wave propagated signals are signals that, generically speaking, travel along
or close to the Earth’s surface on their path between the transmitting and
receiving antennas.  Ground wave signals are the “local” signals we
receive — the signals that are always present at your location, day and
night, regardless of any any particular
atmospheric or ionospheric conditions.

The ground wave actually consists of two
components, the surface wave and the space wave
The terms “surface wave”, “space wave” and “ground wave”
are often used
interchangeably, even though it’s not exactly correct to do so.

The surface wave travels
out from the transmitting antenna, remaining in contact with the Earth’s
surface.  The surface wave is primarily responsible for the reception
of local AM broadcast signals.  The strength of the surface wave
diminishes rapidly with distance because the Earth is a not a particularly
good electrical conductor.  Also, the attenuation of surface wave
signals increases rapidly as the signal frequency is increased.
At FM and TV frequencies the surface wave is virtually
nonexistent.  The surface wave is generally not a factor in our reception of FM
and TV
signals, local or otherwise.

Reception of local FM
and TV signals relies almost entirely upon the space wave component of the ground
wave.  The space wave signal path is the so-called
“line-of-sight” path between the transmit and receive
antennas.  The curvature of the Earth is the primary limiting factor
for the maximum distance a space wave propagated signal can travel.
The space wave will travel outward from the transmitting antenna until it
reaches the horizon.  Beyond that point, the space wave is blocked by
the Earth itself, and reception is no longer possible for a receiver located
on the surface of the Earth (as most are).  It’s important to note,
however, that the optical horizon (the horizon you can see) and the
“radio horizon” are not quite the same.  In reality, the space wave
does not quite travel in a straight line as it moves away from the
transmitting antenna.  Instead, the signal travels in a slightly
downward curved path that keeps it nearer to the Earth’s surface, thus
extending its path a little further than the optical horizon.

If you are into math, the
approximate distance (in miles) to the radio horizon can be calculated by
multiplying the square root of the antenna height (in feet) by 1.415
times.  For example, the theoretical distance to the radio horizon for an antenna
1,000 feet above the ground is just under 45 miles.

 The distance, D1, to the radio horizon for the transmitter is 1.415 times the square root of h1 (feet).  The theoretical maximum line-of-sight distance between two elevated points, presumably the transmitter (h1) and the receiver (h2), is the sum of the two distances to the radio horizon (D1 + D2).

All this, of course, assumes that
the Earth is a perfectly smooth sphere, and that no signal disturbances or
enhancements occur along the path between the transmit and receive
points.  As we know, the Earth is not a perfect sphere, and the space
through which the radio signal travels is not perfect either.  FM
and TV signals can be either attenuated or enhanced by various path
imperfections.  Hills, buildings, trees and other physical obstacles
along the signal path often reduce FM and TV reception distance.  On
the other hand, a variety of atmospheric and ionospheric
conditions serve to enhance our FM and TV reception distance.  We
will
concentrate on the enhancements that  make it possible for VHF and UHF signals
to travel hundreds and even thousands of miles.

Refraction, Refraction, Refraction –  Refraction is defined as “…a change in
direction of a wave as it crosses the boundary that separates one medium
from another.”  While this may sound a little imposing, it’s really a
simple principle of physics — one that we probably observe daily.  Refraction, in one form or another, is the primary
mechanism that enables long-distance FM and TV reception.

 Refraction explains the apparent “bending” of an object when it is partly immersed in water and viewed from above the surface.

As stated earlier, a radio wave travels through a perfect vacuum at the
speed of light (300 million meters per second). However, when the medium
through which the wave travels is not a perfect vacuum, the wave’s travel is
slowed.  For example, an electromagnetic wave travels slower through
air or water than it does through a perfect vacuum.

Refraction comes into play when a wave enters a new medium at an angle of less
than 90°.  As the wave enters the new medium, a change in the wave’s speed occurs sooner on one side of the wave than on
the other.  This causes the wave’s direction of travel to be bent.

Under normal conditions, a signal
that is not blocked or obstructed simply travels in a straight line out into space, never to
However, various atmospheric conditions often cause the normal path of FM and TV signals to be bent
downward, returning the signal to the surface of the Earth, sometimes a
great distance from its point of origin.

Tropospheric Enhancements – Within the broad classification of tropospheric enhancement, there are
several different and distinct propagation modes that make it
possible for FM and TV signals to travel far greater distances than the normal

Tropospheric
Scatter
– Tropospheric scatter is
the most common form of tropospheric enhancement.
Tropo-scatter is always present to some degree just about everywhere.
Tropospheric scatter at FM and TV frequencies is caused when the paths of radio signals are
altered
by slight changes in the refractive index in the lower atmosphere caused by
air turbulence, and small changes in temperature, humidity and barometric
pressure.  The signal is scattered
in random fashion.  The tiny portion of the transmitted signal that is
scattered forward and downward from what is called the “common scattering
volume” is responsible for signal paths longer than
the normal line-of-sight horizon.

 Geometry of Tropo-Scatter Signal Propagation

The height of the scattering volume that is common to both the
transmitting and receiving stations determines the maximum tropo-scatter path distance.
Above about 6 miles refraction in the troposphere becomes insufficient to return
any signal to Earth.

Tropo-scatter enables the reception of signals from
out to about 500 miles, depending primarily on the the power of the
transmitting station and the quality of the receiving equipment being
used.  Maximum tropo-scatter path distances of 200 to 300 are more
typical on a day-to-day basis.  Tropo scattered signals are characteristically weak,
“fluttery” signals that often suffer from random fading.

Tropospheric Refraction – The “standard” atmosphere is
defined as air at sea level having a temperature of 59°
F, a barometric pressure of 29.92 inches of mercury, and a density of
0.002378 slugs per cubic foot.  As we increase altitude within our
standard atmosphere, the temperature, pressure and density decrease at fixed
rates.  The U.S. version of the standard atmosphere table for altitudes up to 10,000
feet looks like this…

 True Altitude above mean sea level Barometric Pressure inches of mercury Temperature Fahrenheit Density slugs per cubic foot 0 29.92 59.0 0.002378 1,000 28.86 55.4 0.002309 2,000 27.82 51.9 0.002242 3,000 26.82 48.3 0.002176 4,000 25.84 44.7 0.002112 5,000 24.89 41.2 0.002049 6,000 23.98 37.6 0.001988 7,000 23.09 34.0 0.001928 8,000 22.22 30.5 0.001869 9,000 21.38 26.9 0.001812 10,000 20.57 23.3 0.001756

As stated previously, when a wave enters a new medium at an angle of less
than 90°, the change in speed occurs sooner on one side of the wave than on
the other, causing the wave to bend.  Close to Earth, the medium
through which radio waves travel is air.  The air through which the
radio wave travels is an ever changing medium due to changes in temperature,
barometric pressure and density.  The “refractive index” of air in a
standard atmosphere is sufficient to bend a radio signal ever so slightly
downward, accounting for the fact that “line-of-sight” signals travel just a
little further than the optical horizon.

 An illustration of why refracted signals go further than the optical line-of-sight.

What happens when the atmosphere does not follow the standard model?
Let’s say everything is “normal” until we get to 4,000 feet, where we
encounter a rise in temperature instead of the normal decrease — a
condition known as a temperature inversion.  The sudden discontinuity
in the medium through which our radio wave travels will have a higher
refractive index than our standard atmosphere model.  In other words, our
radio signal will be bent at a sharper angle where it encounters the
discontinuity.  If the bending is in a downward direction (back toward
the surface of the Earth), the normal range of the radio signal will be
extended.

Various weather conditions increase the refractive index of the
atmosphere, thus extending signal propagation distances.  Stable
signals with good signal strength from 500+ miles away are not uncommon when
the refractive index of the atmosphere is fairly high.

Tropospheric Ducting This is where things start getting interesting for the FM
and TV DXer.
Strong temperature inversions with very well defined boundaries sometimes form from
as high as several thousand feet above the surface of the Earth.  If the
inversion is strong enough,  a signal crossing the boundary into the
inversion will be bent sufficiently to return it to Earth.  The
inversion
boundary layer and the surface of the Earth form the upper and lower walls of a
“duct” that acts much like an open-ended wave guide.  Signals
“trapped” in the duct follow the curvature of the Earth, sometimes for
hundreds or even thousands of miles.  In the tropics and over large bodies of water,
strong inversions that cover large geographic areas are quite common, and stable ducts can remain in tact for days
on end.  This form of
ducting is responsible for fairly reliable propagation between California
and Hawaii at VHF and higher frequencies.

 An illustration of tropospheric ducting.
While somewhat less
common, ducts sometimes form between atmospheric boundary layers at much
higher altitudes, with the upper boundary having an altitude as high as
10,000 feet or more.  The upper refractive layer bends signals
downward, while the lower refractive boundary bends the signals upward,
forming a signal-trapping duct that acts much like a wave guide.
When this condition exists, FM band signals can travel
thousands of miles.  Indeed, there is no theoretical limit to the
distance a signal can travel via tropospheric ducting.  With respect to
the receiving station, tropospherically ducted signals will usually come
from a geographically selective area.  A distant station may be heard
in favor of a closer station on the same frequency.  Sometimes conditions are such that
multiple ducts form, bringing in distant stations from many different areas
at the same time.
 An illustration of a high-altitude tropospheric duct.
An interesting
characteristic of this form of ducting is that both the transmitting and
receiving antennas must be inside of the duct to gain the
maximum signal enhancement.  A receiving antenna located outside of
the duct will hear little or no signal from a transmitting antenna located inside
the duct.  For this type of duct to be useful to us, the signal must
get in and exit the duct somewhere along the signal path.  This can
occur if the ends of a duct are open at each end, or through “holes” that
form along the bottom layer of the duct.
A basic principal
of radio is that the wavelength of a signal gets shorter as the frequency of
the signal is increased.  Because of this, the size of the tropospheric
duct determines the lowest signal frequency that it can successfully
propagate.  This is knows as the Lowest Usable Frequency or LUF of the
duct.  A physically small duct, a duct with its upper and lower
boundaries close together, will propagate only higher frequency signals with
very short wavelengths.  As the distance between the boundaries of the
duct increases, the signal frequency the duct will propagate
decreases.  In other words, a larger duct will accommodate a lower
frequency signal having a physically longer wavelength.  It’s possible
for a duct to form that only supports signal propagation at UHF television
frequencies, while not effectively passing anything in the VHF television or
FM bands.
Ducted signals from 900 – 1,000 miles are fairly common, but
it’s more common for ducted signals to travel 500 – 800 miles.  Ducted
signals are typically quite strong, sometimes so strong that they can cause
interference to local signals on the same frequency.
Weather Suitable for a Duct – Tropospheric
ducting most often occurs because of a dramatic increase in temperature at
higher altitudes.  If the temperature inversion layer has a lower
humidity than the air below or above it, the refractive index of the layer
will be enhanced further.  There are several common weather conditions
that often bring about strong temperature inversions.
While not usually the cause of strong ducting, radiation
inversions can bring about pronounced signal enhancement, extending the DX
range up to a few hundred miles.  This is probably the the most common
and widespread form of inversion a DXer is likely to encounter on a regular
basis.
A radiation inversion forms over land after sunset.
The Earth cools by radiating heat into space.  This is a progressive
process where the radiation of  surface heat upwards causes further
cooling at the Earth’s surface as cooler air moves in to replace the upward
moving warm air.  At higher altitudes the air tends to cool more
slowly, thus setting up the inversion. This process often continues all the
way through the night until dawn, sometimes producing inversion layers at
1,000 to 2,000 feet above the ground.
Radiation inversions are most common during the summer
months on clear, calm nights.  The effect is diminished by blowing
winds, cloud cover and wet ground.  Radiation inversions are often more
pronounced in dry climates, in valleys and over large expanses of flat, open
ground.
Another meteorological process called “subsidence” often
produces strong ducting conditions and excellent DX.  Subsidence is the
process of sinking air that becomes compressed and heated as it descends.
This process often causes strong temperature inversions to form at altitudes
ranging from 1,000 feet to as high as 10,000 feet.  Subsidence is
commonly produced by large, slow-moving high-pressure zones (anticyclones).
These almost stationary high-pressure zones often form over the eastern half
of the United States during the late summer and early fall months.
They usually move out of Canada, traveling toward the southeast.  As
the high-pressure zone stalls over the Midwest, strong inversions form,
bringing outstanding 1,000+ mile DX that can last for days at a time.
This condition is most common in the Southeastern states and lower Midwest.
It also shows up from time to time in the upper Midwest and East Coast
states.  It rarely shows up in the Western states.
The following weather maps are from September 5 and 6 of
2001.  They provide a real-world illustration of tropospheric ducting
associated with a slow moving high-pressure zone.

On September 5th, 2001, a very slow moving high-pressure
zone was pushing out of Canada toward the southeast.  As the high was
centered over Northern Michigan, we observed excellent tropospheric DX
conditions here in Lexington, Kentucky.  Strong FM and TV signals out
of Minnesota, North and South Dakota, Iowa, and Illinois were plentiful
throughout the day.  Signals from 800-900 miles were common.

On September 6, 2001, a full 24 hours later, the sluggish high pressure
zone had moved only as far as western New York.  Here in Lexington, our
DX zone had expanded east.  The 800-900 mile TV and FM signals from the
Midwest were still present, but strong signals from the Northeast as far
away as central Ontario were also added to the mix.  This excellent DX
“opening” lasted almost a full 48 hours.

In the northern hemisphere, the strongest signals and longest signal
paths will usually be observed to the south of the high-pressure center.
In the southern hemisphere, the reverse is true — the best signal paths
will be to the north of the high-pressure center.  Subsidence ducting
is often intensified during the evening and early morning hours when the

Well positioned warm and cold fronts sometimes bring about ducting and
enhanced DX conditions.

A warm front is the surface boundary between a mass of warm air flowing
over an area of cooler, relatively stationary air.  Enhanced DX
conditions will often be observed out to approximately 100 miles ahead of
the advancing front.  The best paths will be along a line parallel to
the frontal boundary.

Likewise, cold fronts can also produce some nice DX conditions.  A cold
front is the surface boundary between a mass of cooler air that pushes
itself under a mass more stationary warm air.  This forces the warm air
up and behind the advancing front.  The ducts produced by a passing
cold front are often unstable.  The best signal paths will be behind
and along a line that’s parallel to the advancing front.

On November 9, 2001, this cold front and well-positioned
high-pressure zone (over southeast Kansas) produced a full day of
outstanding tropospheric FM and TV DX here in Lexington.  We were
solidly open to Arkansas, Alabama, Louisiana and Mississippi.  Path
distances were upwards of 600 miles with very strong signals.

On December 7, 2001, this well positioned cold front
produced excellent DX paths into eastern Tennessee.  This very
geographically selective opening didn’t produce very long signal paths, but
even low power stations were heard with very strong signals.
Since the tropospheric enhancements we’ve covered so far are all weather related,
you can see why it’s important for the DXer to pay attention to day-to-day
weather conditions.

Sporadic E This is probably the most interesting and exciting forms of
signal enhancement for the FM and TV DXer.  Highly ionized patches or
“clouds” occasionally form in the E region of the ionosphere at
altitudes between approximately 50 and 70 miles.  We call these
size, but larger clouds or multiple clouds often form during substantial
openings.  These clouds often, but not always, travel from their point of
origin
to the north and  northwest at speeds up to several hundred miles per hour.

It’s interesting to
note that after almost 70 years of study the true cause for sporadic E is
still unknown.  There are many different theories as to how and why

It was once
believed that the formation of sporadic E clouds was directly related to
the eleven year solar (sunspot) cycle. You’ll still see that theory expressed in some
text books even though overwhelming evidence suggests that this belief
is wrong.  There seems to be no correlation between the ionization
level or formation of sporadic E clouds and the eleven year sunspot cycle – at
least not in the mid latitudes away from the geomagnetic equator and
poles.  It was noted all the way back in the 1930s and 1940s that the
formation and intensity of mid-latitude sporadic E clouds does not
substantially vary over the course of the eleven year solar cycle.

There is evidence
to suggest that the primary cause of sporadic E cloud formation is wind
shear, a purely weather-related phenomenon. Intense high altitude winds,
traveling in opposite directions at different altitudes, produce wind
shear.  It is believed that these wind shears, in the presence of
Earth’s geomagnetic field, cause ions to be collected and compressed into a
thin, ion-rich layers, approximately one-half to one mile in
thickness.  The area of these patches can vary from a few square miles
to hundreds or even thousands of square miles.

Along the same line
is the theory that sporadic E clouds are formed in the vicinity of
thunderstorms by the intense electrical activity associated with the
storm.  There is often (but not always) a correlation between
thunderstorm activity and the formation of sporadic E clouds, enough to make
this theory very tantalizing.  However, strong thunderstorms often form
along frontal boundaries, and intense wind sheer is usually found along the
same frontal boundaries that produce thunderstorms.  Likewise, strong
sporadic E activity often appears when there is no apparent thunderstorm
activity along or near the propagation path.

Yet another
emerging theory suggests that sporadic E clouds are formed by concentrations
of meteoric debris.  Again, there seems to be a strong correlation between meteor
shower activity and the number and intensity of sporadic E clouds.

The point is,
nobody has presented a definitive explanation for how and why sporadic E
clouds form. There are many excellent papers on the subject.  Just
clouds are formed as the result of a combination of factors, perhaps involving wind shear,
cosmic debris and thunderstorm activity.

The amount by which
the path of a radio signal is refracted by sporadic E clouds depends on the
intensity of ionization and the frequency of the signal.  For a
given level of ionization, the signal refraction angle will decrease as the
frequency is increased.  Above a certain critical frequency, refraction
of the signal will be insufficient to return it to the surface of the
Earth.  This critical frequency is known as the Maximum Usable
Frequency or MUF.

Sporadic E is very common on the low VHF TV
channels during the summer months.  From time to time, the intensity of Sporadic E cloud
ionization increases to the point where the MUF rises into and sometimes
above FM band
frequencies (88 to 108 MHz).  It is common for the MUF to rise up to
and then stop at a particular frequency within the FM band.
Distant signals will be heard below the MUF, while only local or
tropospherically enhanced signals will be heard above the MUF.  It has
been observed over the years that the signal strength of received sporadic E
signals will be greatest just below the Maximum Usable
Frequency.  Also, since the bending angle (angle of refraction) decreases as signal frequency
is increased for a given ionization level, we can surmise that the most
distant receptions will occur as we approach the MUF.  In other
words, an Es cloud will support longer signals paths at 100 MHz than it will
at 50 MHz.

The above illustration shows an actual Es cloud
configuration and the associated skip zone that occurred during the summer
of 2001.  Three different DXers are
represented by the numbers 1, 2 and 3.  The Es cloud was
over Eastern Kansas and Western Missouri.  The yellow band is the DX
zone.  Using the same sporadic E cloud, a DXer in
one part of the country will hear one assortment of stations while a DXer in
a different part of the country will hear a completely different set of
stations.  If the DXers were to plot lines between their respective
locations and the stations they were each hearing (as I did here), the
approximate location of the sporadic E cloud will be above where the lines
intersect.  You will note that both the DXer and the stations being
received are in the yellow shaded DX zone.  DXers outside the yellow
shaded zone did not benefit from this particular Es
cloud.
DXer #1 (me), located in Lexington, KY, heard stations in New
Mexico and Colorado.  DXer #2, in West Texas heard stations in
Wisconsin and Michigan.  DXer #3, located in Western South Dakota heard stations in Mississippi and Alabama.
Es signal paths are usually bi-directional.  In other
words, if the DXer in Kentucky is hearing FM stations in Colorado, a DXer in Colorado
will be able to hear stations in Kentucky.

Since Es clouds
often move with respect to the receiving station, the DXer will
often hear a changing selection of distant signals.

Various geometries of Sporadic E Signal Propagation

This illustration shows three sporadic E clouds.
Cloud #1 is more intensively ionized, and is thus capable of refracting
signals at a sharper angle, producing a shorter skip distance for a given
frequency.  Signals being refracted by Cloud #2 are returned to Earth
at a lesser angle, thus producing longer skip distances.  With clouds
#2 and #3 in alignment along the signal path, “double-hop” skip can occur.
With this cloud alignment signals from both the “transmitter” and the
“Single-Hop Zone” would be heard at the receiver location.

A sporadic E cloud producing short to medium
distance skip at lower frequencies (TV channel 2, for example) is likely to
produce longer skip at FM frequencies if the MUF is high enough.

The maximum
distance for a single-hop sporadic E propagated signal is approximately

1,500 miles.  However, if multiple, sufficiently ionized
patches exist in a line along a particular signal path, it’s possible for a
given signal to reflect off the surface of the Earth after the first hop and
get refracted back to Earth by a second sporadic E cloud.  This can
extend the range of E-layer propagated signals out to 3,000 miles and
beyond.  Statistically speaking, the “average” skip distance
for sporadic E propagated FM DX seems to be between 950 and 1,050 miles.
During 2001 I received 205 stations via sporadic E (a decent statistical
sample).  The average distance of these receptions was 997 miles.

Single-hop E-layer propagated signals are often as
strong as local signals.  Indeed, I have witnessed more than one
situation where a local station was completely “covered” by a distant one,
only a few miles from the local station’s transmitter location (that’s when
they call the engineer to see if he can “fix” the problem).  Since the
surface of the Earth is not a very good signal reflector, multi-hop E-layer
propagated signals will usually be weaker than single-hop signals, and are
often covered by signals coming from stations in the single hop zone.
If the mid-point of a double-hope happens to be on water (such as the
ocean), the signals will be stronger and the there will likely be no
interference from mid-point stations (unless someone happens to be operating
an FM or TV broadcast station aboard a ship!).

Sometimes we hear stations via Sporadic E that don’t seem to fit the
normal model in terms of path distance.  It’s not uncommon to receive
signals beyond the range of what would be considered “normal” for a single
hop, but at less than the range expected for “normal” double hop.

Many theories have been advanced to explain this phenomenon, including
paths along multiple, tilted sporadic E clouds.  Here’s an illustration
of how this might work.

Geometry of “Tilted” Es Cloud-to-Cloud Signal Propagation
Based on both Earth and satellite based ionosonde readings
and readings from rockets sent through Es clouds, it is known that tilted Es
clouds do form.  As such, this theory does provide at least one
plausible explanation for longer than “normal” Es signal propagation paths.
I think there is another, simpler means by which Es signals
are propagated longer than “normal” distances out to almost double-hop
distances.  This would also account for receptions where signals from
double-hop distances are received without the usual interference from
stations in the single hop zone.

Geometry of “Non-Tilted” Es Cloud-to-Cloud Signal Propagation
In this illustration, neither Es cloud is sufficiently
ionized to return a single-hop signal to Earth.  However, with the two
“weak” clouds working together, the refraction angles of each Es cloud are
essentially added.  This would have the effect of raising the apparent
Maximum Usable Frequency and ultimately returning the signal to Earth at a
greater than  “normal” Es distance.  This is a somewhat more
simple (thus more likely) Es cloud configuration than that of the “tilted”
cloud theory.  It would account for variable path distances which fall
between that of “normal” single- and double-hop sporadic E path distances.
In theory, a similar configuration could exist with three or
more Es clouds, producing much longer signal paths.  However, as the
complexity of the signal path geometry increases, the likelihood of such
configurations forming and becoming usable diminishes.
Other Es cloud configurations are certainly possible.
Picture, for example, a larger sporadic E cloud, which is not uniformly
ionized…

Possible Path Geometry of a Large Es Cloud with Non-uniform Ionization
A signal entering the “weaker” side of the large Es cloud
Es cloud that is more intensely ionized.  Ionization in this region of
the Es cloud is sufficient to return the signal to Earth.  The effect
of such a configuration is not fundamentally different than the tilted cloud
or cloud-to-cloud examples presented above.  It is  another
possible means by which Es signals can be propagated longer than “normal”
single-hop distances.

In the northern
hemisphere, seasonal sporadic E season peaks occur during the months of May,
June and July.  An additional minor peak often occurs in late December
around Christmas time when the Sporadic E season is at its summertime peak
in the southern hemisphere.  One theory to explain this phenomenon is
that intense sporadic E clouds formed in the vicinity of the equator manage
to hold their configuration as they drift toward the north and northwest, thus
producing our short December sporadic E DX season.   The best time
of day for sporadic E seems to be mid morning and mid afternoon.
However, sporadic E DX can happen at anytime, day or night, and can pop up
any time of the year.  Sporadic E DX usually lasts from a few minutes
to a few hours.  However, I’ve seen it last several full days and
nights, causing a great lack of sleep!

Aurora Effect
During periods of high solar and geomagnetic activity, aurora or
“northern lights” may be present.  FM signals can be returned
to Earth from the auroral curtain.  However, the constantly varying
intensity of the aurora and its highly variable reflectivity give auroral
propagated signals a fluttery quality.  The flutter will usually be in
the range of 100 Hz to 2,000 Hz, producing a “buzz” in the received signal.  In some cases, this effect can be so
strong, normal voice or music modulation ends up becoming distorted to the
point of unintelligibility.  In the northern hemisphere, auroral propagated signals will
generally come from the north, regardless of the true direction of the
transmitting station.

 Look for aurorally-propagated signals following major solar activity, or the announcement that visible northern lights will be seen near your area.  Obviously, the further south you live, the less likely you are to hear auroral enhanced radio signals.  The best place for auroral effect in the United States is in Alaska or the Northeastern states.  It’ll be rare below latitude 32 in the Southeast and latitude 38 to 40 in the West and Southwest.

The theoretical maximum distance
for Auroral enhanced signals is about 1,300 miles. 200 to 800 miles is
typical.  High quality, very sensitive, receiving equipment is required for this DX mode.

Meteor Scatter – This
interesting form of enhancement results from signals bouncing off of the intensely
ionized trails of meteors entering and  “burning up” in the E
region of the ionosphere.  The strength and duration of meteor scatter
signals decreases with increasing frequency.  Thus, the effect is much
more pronounced at the lower FM band frequencies than at the upper end of
the band.  Meteor scatter can be heard anywhere, anytime of the day or
night.  However, bursts are more plentiful around dawn, and during
known major meteor showers.

 The radio signal returns to Earth after bouncing off the meteor trail.

Meteor scatter is characterized by
a sudden, short burst of a distant, strong signal.  The length of the
burst depends upon the length and intensity of the ionized meteor
trail.  They can be as short as a fraction of a second, producing a
short “ping” at the receiver.  Larger meteors, or meteors
entering atmosphere at a glancing angle, have been known to produce signal
bursts lasting up to several minutes.  If you try, you’ll hear many
meteor scatter signals.  However, you have to be lucky to actually
catch a station identification at exactly the same instant the meteor burst
occurs.  High quality equipment helps, but meteor bursts can even be
heard on the “average” car radio if you know what to listen for..

Summary – There are other, more esoteric signal propagation
modes that are often at work to enhance long-distance reception of FM
signals.  Signals bounce off of airplanes and even formations of birds.
With the right equipment, it’s even theoretically possible to recover
broadcast signals bounced off the surface of the moon!  However, the
propagation modes outlined above are the more common ones you are likely to
encounter while FM DXing.

Note:  All the propagation mode illustrations shown here, are
obviously not drawn to scale.  The signal “bending” angles
shown are very exaggerated.  In reality, they are usually fairly slight
angles.
